DPP-270/360A Flat Type ALU-PVC/ALU Blister Packing Machine

Byhanyoo
Share on Pinterest Share on LinkedIn Share on WhatsApp

The blister packing machine is special for pharmaceutical, food, chemical industrial usage. It has the function of packaging, detecting, rejection.It adopted PLC control system, touch screen interface, frequency converter system, which make the machine automatic running more stable and enhanced the machine life time. The machine can use ALU PVC, ALU ALU, PVC PAPER material for blister packaging. It meet GMP standard.

Play

Properties

ModelDPP-270ADPP-360A
Cutting Frequency(times/min)ALU-PVC10-40ALU-PVC10-40
ALU-ALU10-20ALU-ALU10-20
Output Capacity(pcs/h)ALU-PVC4000-7000ALU-PVC6000-9000
ALU-ALU2000-3000ALU-ALU3000-5000
Travel(mm)30-130(150)30-150(180)
Max.Blister Size270*130(150)*30(40)mm360*150(180)*30 (50)mm
Air Consumption≥0.38m³/min≥0.42m³/min
Voltage380V50HZ/220V 60HZ380V50HZ/220V 60HZ
Plastic Film(mm)280*(0.15-0.5)360*(0.15-0.5)
Aluminum Foil(mm)280*(0.02-0.035)360*(0.02-0.035)
Over Size(mm)3900*740*17004560*740*1700
Weight(kg)17001700

Machine Features

  • Uses internationally renowned imported touchscreens and other electrical components. Easy to operate and maintain, with automatic error alarms to protect the equipment. The traction length can be set via the touchscreen.
  • The mold changeover is simple. With locating pins, the mold replacement and debugging time does not exceed 30 minutes when operated by an experienced user.
  • The machine integrates both Alu-PVC (aluminum-plastic) and Alu-Alu packaging. By changing the molds and feeder, it can package Alu-PVC and Alu-Alu products.

Production Workflow Chart

Sample Display

Detailed Display

Exhibition

Packaging And Shipping

Why Choose Us

Specialized Factory

Economical Pricing Options

On-Time Delivery

Perfect Customer Service

If you have any questions or need to develop customized equipment solutions, please contact our Email：hanyoo.jason@foxmail.com for the most thoughtful support!

Welcome To Our Blister Packing Machine Line Factory!

Frequently Asked Questions

A blister pack is a form of tamper-evident packaging where an individual pushes individually sealed tablets through the foil in order to take the medication.

Blister packaging is a cost-effective way of showcasing a product. Due to the nature of the material and design, it makes it more cost-effective than other types of packages that are on the market.

Liquids, drops, creams, powders, inhaled, or injected medications cannot be blister packed and should be turned in to the health team in their original packaging.
